UL-Listed Platform

NL·01 · Hardwired & plug-in · J1772 & NACS

Level 2 · Home Charging

NorthernLit 1

A wall-mounted Level 2 home charger built for the North: 12 kW of quiet power, a soft aurora status panel, a 25 ft cable that stays flexible in the cold — and a sealed, snow-shedding body that belongs on your wall.

CA$1,199 MSRP · Hardwired & Plug-in

Installation quoted separately by a licensed electrician.

ConnectorJ1772
InstallationHardwired

Hardwired gives you the full 12 kW — the fastest charge your home can safely deliver.

Request a quote Ask about installation
3-Year Warranty UL-Listed Platform Designed in Canada Free shipping in Canada

01Key Specification

The numbers behind the calm

Specifications update with your selection above. Full technical datasheet available on request.

Electrical

AC power output
Up to 12 kW240 V AC, single phase
AC power input
208 / 240 V AC · 60 HzSingle phase
Output current
Configurable at installationSet to match your home's circuit capacity
Wiring
3 wire — L1, L2 + earthNo neutral required

Connector & cable

Connector type
J1772
Charging cable
7.6 m / 25 ftCold-flexible jacket with connector holster
Installation
HardwiredDirect connection to a dedicated circuit

Interface & build

Status interface
Aurora LED status panelCharge state readable across the garage
Connectivity
Wi-Fi with over-the-air updatesCompanion app for scheduling and live status
Enclosure
Weather-sealed, indoor / outdoor ratedSealed against rain, snow and road salt
Mounting
Wall mountMounting hardware and template included
Warranty
3 yearsRegistered at purchase; full terms on request

02Charging Speed

Up to 12 kWh every hour

Compare what a dedicated Level 2 circuit puts into your battery each hour.

NorthernLit 1Hardwired · 240 V
12 kW
NorthernLit 1NEMA 14-50 · 240 V
9.6 kW
Portable Level 2Typical 240 V cord set
7.0 kW
Household outletLevel 1 · 120 V
1.4 kW

Figures describe the energy delivered by the charging equipment, not the range added — actual charging speed depends on your vehicle's on-board charger and state of charge. Level 1 and portable Level 2 values describe commonly available household equipment.

03Design & Details

Small details, daily payoff

/01

Aurora status panel

One glance tells you everything: charging, topped up, or night-quiet.

  • Readable from across a two-car garage
  • Low-glare illumination for quiet residential streets
Pink and green aurora over a silhouetted evergreen tree line at night

/02

Built for the north

No exposed vents, so rain, snow and road salt stay outside. The jacket stays flexible down to −20 °C.

  • Indoor and outdoor wall mounting
  • 25 ft cable reaches a second driveway bay
Car parked in deep snow after a winter storm

/03

Scheduled, monitored, updated

Charge overnight when power is cheapest. Watch status from your phone.

  • Scheduling and reminders
  • Live session and energy reporting
  • Firmware updates over Wi-Fi

04Installation

Two ways to plug in

Both configurations are performed by a licensed electrician — we'll connect you with an installer in your area.

Fastest

Hardwired

Direct from your panel. No plug, no outlet — full 12 kW.

Up to 12 kW output Cleanest wall finish, tamper-resistant Best choice for a permanent home setup
Most flexible

NEMA 14-50 plug

Into an existing 240 V outlet. Ideal if you may move the charger later.

Up to 9.6 kW on a 40 A continuous circuit Takes the charger with you when you move Requires a dedicated 240 V receptacle
S·01

Home assessment

Share your panel capacity and parking layout. We'll tell you which configuration fits before anyone touches a wall.

S·02

Licensed installation

A licensed electrician handles the circuit, mounting and commissioning — typically a single visit.

S·03

Pair and charge

Connect the charger to your Wi-Fi, set a schedule, plug in — and let the aurora light do the talking.

Installation must be performed by a licensed electrician, and a permit or inspection may be required in your municipality. Every home is different: available panel capacity, circuit length and local code determine the final configuration and cost.

05In the box

Everything for install day

Charging stationThe NorthernLit 1 wall unit with pre-fitted mounting bracket.
25 ft cable & connectorJ1772 or NACS, with a wall holster for tidy storage.
Mounting templateDrill guide so the holes land exactly where they should.
Mounting hardwareLag screws and wall anchors rated for a loaded enclosure.
Quick-start guidePairing, scheduling and support contacts in one page.

05Smart charging

Charge on your schedule

NorthernLit 1 speaks the open OCPP 1.6J standard and connects over Wi-Fi, so it drops into the charging app or network you already use — no locked-in platform.

Scheduled chargingSet off-peak windows so the car is ready each morning and the bill stays low.
Live status & alertsSee charge state and get notified when charging starts, finishes or faults.
Open standardOCPP 1.6J means any compliant app or backend can manage the unit — yours to choose.
Over-the-air updatesWi-Fi keeps the firmware current, so features and fixes arrive without a service call.

06Questions

Before you buy

Will NorthernLit 1 charge my car?
NorthernLit 1 is available with the two connector standards used by electric vehicles sold across North America — J1772 and NACS. If your vehicle has either inlet, you can charge at full Level 2 speed. Not sure which one you need? Tell us your make and model and we'll confirm before you order.
Should I choose hardwired or the NEMA 14-50 plug?
Choose hardwired for the full 12 kW and the cleanest installation — it's the right answer for a home you plan to stay in. Choose the NEMA 14-50 plug if you already have a 240 V receptacle in your garage or may move the charger to another property. Plug-in installation delivers up to 9.6 kW.
What does my electrician need to know?
Your installer will confirm available panel capacity and run a dedicated circuit for the charger. Installation must be carried out by a licensed electrician, and a permit or inspection may be required locally. We can share the technical documentation your electrician needs — just request it by email.
How is it mounted, and can it go outdoors?
NorthernLit 1 mounts to any suitable wall with the included bracket, template and hardware. The enclosure is weather-sealed and rated for indoor and outdoor use, so a garage, carport or exterior wall by the driveway all work — your electrician will confirm the best position and cable routing.
What does the warranty cover?
Every NorthernLit 1 is covered by a 3-year warranty. Full terms — what's covered, what isn't, and how to make a claim — are published in our Warranty & Sales Terms, and are included with your unit's documentation.
How do I order, and who installs it?
Reach out with your vehicle and a photo of your electrical panel. We'll confirm the right configuration, quote the unit, and connect you with an installation partner in your area. Charging hardware and installation are quoted separately so you always know what you're paying for.

07Get started

Ready to charge
at home?

info@clinkinnovations.com
Tell us

Your vehicle make and model, your parking setup, and a photo of your electrical panel.

We'll come back with

The right connector and installation configuration, a quote, and an installer introduction.

Head office

Richmond Hill, Ontario, Canada

08Order

Order NorthernLit 1

Tell us your vehicle and a photo of your panel. We confirm the configuration, quote the unit, and connect you with a local installer.

Request a quote
Level 2 · J1772Hardwired 12 kW, or 9.6 kW on a 14-50 plug Level 2 · NACSSame charger, NACS inlet.

Not sure which fits? Ask us first — we confirm the configuration before you pay.

NorthernLit 1J1772 · Hardwired · 12 kW
CA$1,199
Request a quote
